Description

Engine

Engine Brand Name: Evolution(R)

Engine Type: V Twin

Cylinders: 2

Engine Stroke: 4-Stroke

Torque (Ft Lbs/Nm): 53.8 / 72.9

Torque RPM: 3750

Cooling: Air

Valves: 4

Valves Per Cylinder: 2

Valve Configuration: OHV – Pushrod

Bore (mm/in): 76.2 / 3

Stroke (mm/in): 96.8 / 3.81

Displacement (cc/ci): 883 / 53.9

Compression Ratio: 9.0:1

Starter: Electric

Fuel Requirements: Regular

US Miles Per Gallon (Combined): 51

CAN Liters Per Kilometer (Combined): 4.6

Fuel Type: Gas, Fuel Injected

Transmission

Transmission Type: Manual, 5 speed.

Primary Drive (Rear Wheel): Belt

Primary Drive (Engine / Transmission): Chain

Gear Ratio (1/2/3/4/5): 10.41 / 7.436 / 5.531 / 4.584 / 3.931

Wheels & Tires

Wheels Composition: Steel

Tire Brand: Michelin(R)

Front Tire Width: 100

Front Tire Aspect Ratio: 90

Front Tire Speed Rating: H

Front Wheel Diameter: 19

Rear Tire Width: 150

Rear Tire Aspect Ratio: 80

Rear Tire Speed Rating: H

Rear Wheel Diameter: 16

Front Tire (Full Spec): Michelin(R) Scorcher(TM) 100/90 R19 57H

Rear Tire (Full Spec): Michelin(R) Scorcher(TM) 150/80 R16 77H

Brakes

Front Brake Type: Hydraulic Disc

Front Brake Diameter (in/mm): 11.8 / 300

Rear Brake Type: Hydraulic Disc

Rear Brake Diameter (in/mm): 11.8 / 300

Suspension

Front Suspension Type: Telescopic Fork

Front Suspension Size (in/mm): 36 / 914.4

Rear Suspension Type: Twin Sided Swing Arm

Rear Adjustable Shock / Spring Pre-Load: Yes

Number Rear Shock Absorbers: 2

Rear Suspension Material: Steel

Steering

Steering Control: Handlebar

Technical Specifications

Length (ft): 7.17

Width (in/mm): 32.1 / 815

Height (in/mm): 44.9 / 1140

Wheelbase (in/mm): 59.6 / 1515

Ground Clearance (in/mm): 5.5 / 140

Length (ft/ft): 7

Length (ft/in): 2

Dry Weight (lbs/kg): 545 / 247.2

Wet Weight (lbs/kg): 564 / 256

Payload Capacity (lbs/kgs): 436 / 198

GVWR (lbs/kgs): 1000 / 454

Fuel Capacity (gal/l): 3.3 / 12.5

Engine Displacement to Weight (cc): 1.62

Seats

Seat Type: One-Piece

Seat Material: Leather

Seat Height (in/mm): 29.9 / 759.5
